Type
5/2
Design
Internal Pilot Operated Poppet Valve
Port Size
In / Out / Exhaust - ¼
Media
Compressed Air (Filtered & Lubricated)
Working Pressure Range
2-10 Bar
Orifice
7mm
Ambient/Medium Temperature
5°C - 60°C
Flow
18 kv (LPM of Water @ 1 bar ΔP)
Materials of Construction
Aluminium, Nitrile, Brass, Polymer
Operating Voltage & Power Consumption
| 24V AC | 110V AC | 230V AC | 12V DC | 24V DC |
| 9W | 9W | 9W | 10W | 11W |
Coil Features
High Reliability Unaffected by Voltage Surges. Easy coil changes coil lockable in 4X90 position or freely movable in between as require
Coil Housing
IP65 Epoxy square coil, IP65 Metallic round enclosure, IP67 Flameproof Junction box, IP68 Weatherproof enclosure
- Fast Response time 1000 cycle/min
- Manual override
- 10 Million cycle tested
- Lubrication not essential
| Model No. | Function | Symbol |
|---|---|---|
| DCP-D1ET070 | Single Solenoid Spring Return |  |
