Type
3 Way
Design
3 Way Direct Acting Poppet Type
Port Size
In / Out / Exhaust - ¼
Media
Compressed Air (Filtered & Lubricated)
Working Pressure Range
0-10 Bar
Orifice
10mm
Ambient/Medium Temperature
5°C - 60°C
Materials of Construction
Aluminium, Nitrile, Brass, Polymer
Operating Voltage & Power Consumption
| 24AC | 110AC | 230AC | 12DC | 24DC |
| 9W | 9W | 9W | 10W | 11W |
Coil Features
High Reliability Unaffected by Voltage Surges. Easy coil changes coil lockable in 4X90 position or freely movable in between as required.
Coil Housing
Epoxy square coil, Metallic round enclosure, IP-67 Flameproof enclosure, IP-68 Weatherproof enclosure.
- Fast response time 1000 cycles/min.
- Manual Override.
- 2 Million cycles were tested.
- Lubrication is not essential.
| Model No. | Function | Symbol |
|---|---|---|
| TAN204BNIT100V0 | Single Solenoid Spring Return |  |
| TAN204BNJT100V0 |
